#include <BaseVolume.h>

Inheritance diagram for PolyVox::BaseVolume< VoxelType >:

Collaboration diagram for PolyVox::BaseVolume< VoxelType >:

Classes
class	Sampler
Public Member Functions
	BaseVolume (const Region &regValid)
	Constructor for creating a fixed size volume.
	~BaseVolume ()
	Destructor.
VoxelType	getBorderValue (void) const
	Gets the value used for voxels which are outside the volume.
Region	getEnclosingRegion (void) const
	Gets a Region representing the extents of the Volume.
int32_t	getWidth (void) const
	Gets the width of the volume in voxels.
int32_t	getHeight (void) const
	Gets the height of the volume in voxels.
int32_t	getDepth (void) const
	Gets the depth of the volume in voxels.
int32_t	getLongestSideLength (void) const
	Gets the length of the longest side in voxels.
int32_t	getShortestSideLength (void) const
	Gets the length of the shortest side in voxels.
float	getDiagonalLength (void) const
	Gets the length of the diagonal in voxels.
VoxelType	getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by `x,y,z` coordinates.
VoxelType	getVoxelAt (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.
void	setBorderValue (const VoxelType &tBorder)
	Sets the value used for voxels which are outside the volume.
bool	setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue)
	Sets the voxel at the position given by `x,y,z` coordinates.
bool	setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue)
	Sets the voxel at the position given by a 3D vector.
uint32_t	calculateSizeInBytes (void)
	Calculates approximatly how many bytes of memory the volume is currently using.
Protected Attributes
Region	m_regValidRegion
int32_t	m_uLongestSideLength
int32_t	m_uShortestSideLength
float	m_fDiagonalLength

Detailed Description

template<typename VoxelType>
class PolyVox::BaseVolume< VoxelType >

Definition at line 37 of file BaseVolume.h.

Constructor & Destructor Documentation

template<typename VoxelType >

PolyVox::BaseVolume< VoxelType >::BaseVolume ( const Region & regValid )

Constructor for creating a fixed size volume.

Definition at line 28 of file BaseVolume.inl.

template<typename VoxelType >

PolyVox::BaseVolume< VoxelType >::~BaseVolume ( )

Destructor.

Destroys the volume.

Definition at line 39 of file BaseVolume.inl.

Member Function Documentation

template<typename VoxelType >

uint32_t PolyVox::BaseVolume< VoxelType >::calculateSizeInBytes ( void )

Calculates approximatly how many bytes of memory the volume is currently using.

Note: This function needs reviewing for accuracy...

Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::RawVolume< VoxelType >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::LargeVolume< int32_t >.

Definition at line 191 of file BaseVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getBorderValue ( void ) const

Gets the value used for voxels which are outside the volume.

The border value is returned whenever an attempt is made to read a voxel which is outside the extents of the volume.

Returns:: The value used for voxels outside of the volume

Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::RawVolume< VoxelType >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::LargeVolume< int32_t >.

Definition at line 49 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getDepth ( void ) const

Gets the depth of the volume in voxels.

Returns:: The depth of the volume in voxels. Note that this value is inclusive, so that if the valid range is e.g. 0 to 63 then the depth is 64.

See also:: getWidth(), getHeight()

Definition at line 89 of file BaseVolume.inl.

Referenced by PolyVox::RawVolume< VoxelType >::calculateSizeInBytes(), PolyVox::BaseVolume< VoxelType >::calculateSizeInBytes(), PolyVox::SimpleVolume< VoxelType >::resize(), PolyVox::RawVolume< VoxelType >::resize(), and PolyVox::LargeVolume< VoxelType >::resize().

Here is the call graph for this function:

template<typename VoxelType >

float PolyVox::BaseVolume< VoxelType >::getDiagonalLength ( void ) const

Gets the length of the diagonal in voxels.

Returns:: The length of the diagonal in voxels. For example, if a volume has dimensions 256x512x1024 this function will return sqrt(256*256+512*512+1024*1024) = 1173.139. This value is computed on volume creation so retrieving it is fast.

See also:: getShortestSideLength(), getLongestSideLength()

Definition at line 123 of file BaseVolume.inl.

template<typename VoxelType >

Region PolyVox::BaseVolume< VoxelType >::getEnclosingRegion ( void ) const

Gets a Region representing the extents of the Volume.

Returns:: A Region representing the extent of the volume.

Definition at line 59 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getHeight ( void ) const

Gets the height of the volume in voxels.

Returns:: The height of the volume in voxels. Note that this value is inclusive, so that if the valid range is e.g. 0 to 63 then the height is 64.

See also:: getWidth(), getDepth()

Definition at line 79 of file BaseVolume.inl.

Referenced by PolyVox::RawVolume< VoxelType >::calculateSizeInBytes(), PolyVox::BaseVolume< VoxelType >::calculateSizeInBytes(), PolyVox::RawVolume< VoxelType >::getVoxelAt(), PolyVox::SimpleVolume< VoxelType >::resize(), PolyVox::RawVolume< VoxelType >::resize(), PolyVox::LargeVolume< VoxelType >::resize(), and PolyVox::RawVolume< VoxelType >::setVoxelAt().

Here is the call graph for this function:

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getLongestSideLength ( void ) const

Gets the length of the longest side in voxels.

Returns:: The length of the longest side in voxels. For example, if a volume has dimensions 256x512x1024 this function will return 1024.

See also:: getShortestSideLength(), getDiagonalLength()

Definition at line 111 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getShortestSideLength ( void ) const

Gets the length of the shortest side in voxels.

Returns:: The length of the shortest side in voxels. For example, if a volume has dimensions 256x512x1024 this function will return 256.

See also:: getLongestSideLength(), getDiagonalLength()

Definition at line 100 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)			const

Gets a voxel at the position given by x,y,z coordinates.

Parameters:

	uXPos	The `x` position of the voxel
	uYPos	The `y` position of the voxel
	uZPos	The `z` position of the voxel

Returns:: The voxel value

Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::RawVolume< VoxelType >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::LargeVolume< int32_t >.

Definition at line 135 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelAt ( const Vector3DInt32 & v3dPos ) const

Gets a voxel at the position given by a 3D vector.

Parameters:

v3dPos

The 3D position of the voxel

Returns:: The voxel value

Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::RawVolume< VoxelType >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::LargeVolume< int32_t >.

Definition at line 146 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getWidth ( void ) const

Gets the width of the volume in voxels.

Returns:: The width of the volume in voxels. Note that this value is inclusive, so that if the valid range is e.g. 0 to 63 then the width is 64.

See also:: getHeight(), getDepth()

Definition at line 69 of file BaseVolume.inl.

Referenced by PolyVox::RawVolume< VoxelType >::calculateSizeInBytes(), PolyVox::BaseVolume< VoxelType >::calculateSizeInBytes(), PolyVox::RawVolume< VoxelType >::getVoxelAt(), PolyVox::SimpleVolume< VoxelType >::resize(), PolyVox::RawVolume< VoxelType >::resize(), PolyVox::LargeVolume< VoxelType >::resize(), and PolyVox::RawVolume< VoxelType >::setVoxelAt().

Here is the call graph for this function:

template<typename VoxelType>

void PolyVox::BaseVolume< VoxelType >::setBorderValue ( const VoxelType & tBorder )

Sets the value used for voxels which are outside the volume.

Parameters:

tBorder

The value to use for voxels outside the volume.

Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::RawVolume< VoxelType >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::LargeVolume< int32_t >.

Definition at line 156 of file BaseVolume.inl.

template<typename VoxelType>

bool PolyVox::BaseVolume< VoxelType >::setVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by x,y,z coordinates.

Parameters:

	uXPos	the `x` position of the voxel
	uYPos	the `y` position of the voxel
	uZPos	the `z` position of the voxel
	tValue	the value to which the voxel will be set
