#include <RawVolume.h>

Inheritance diagram for PolyVox::RawVolume< VoxelType >:

Collaboration diagram for PolyVox::RawVolume< VoxelType >:

Classes
class	Sampler
Public Member Functions
	RawVolume (const Region &regValid)
	Constructor for creating a fixed size volume.
	~RawVolume ()
	Destructor.
VoxelType	getBorderValue (void) const
	Gets the value used for voxels which are outside the volume.
VoxelType	getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by `x,y,z` coordinates.
VoxelType	getVoxelAt (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.
void	setBorderValue (const VoxelType &tBorder)
	Sets the value used for voxels which are outside the volume.
bool	setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue)
	Sets the voxel at the position given by `x,y,z` coordinates.
bool	setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue)
	Sets the voxel at the position given by a 3D vector.
uint32_t	calculateSizeInBytes (void)
	Calculates approximatly how many bytes of memory the volume is currently using.
void	resize (const Region &regValidRegion)
	Deprecated - I don't think we should expose this function? Let us know if you disagree...

Detailed Description

template<typename VoxelType>
class PolyVox::RawVolume< VoxelType >

Definition at line 41 of file RawVolume.h.

Constructor & Destructor Documentation

template<typename VoxelType >

PolyVox::RawVolume< VoxelType >::RawVolume ( const Region & regValid )

Constructor for creating a fixed size volume.

This constructor creates a volume with a fixed size which is specified as a parameter.

By default this constructor will not enable paging but you can override this if desired. If you do wish to enable paging then you are required to provide the call back function (see the other RawVolume constructor).

Parameters:

	regValid	Specifies the minimum and maximum valid voxel positions.
	dataRequiredHandler	The callback function which will be called when PolyVox tries to use data which is not currently in momory.
	dataOverflowHandler	The callback function which will be called when PolyVox has too much data and needs to remove some from memory.
	bPagingEnabled	Controls whether or not paging is enabled for this RawVolume.
	uBlockSideLength	The size of the blocks making up the volume. Small blocks will compress/decompress faster, but there will also be more of them meaning voxel access could be slower.

Definition at line 36 of file RawVolume.inl.

template<typename VoxelType >

PolyVox::RawVolume< VoxelType >::~RawVolume ( )

Destructor.

Destroys the volume.

Definition at line 51 of file RawVolume.inl.

Member Function Documentation

template<typename VoxelType >

uint32_t PolyVox::RawVolume< VoxelType >::calculateSizeInBytes ( void )

Calculates approximatly how many bytes of memory the volume is currently using.

Note: This function needs reviewing for accuracy...

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 186 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

VoxelType PolyVox::RawVolume< VoxelType >::getBorderValue ( void ) const

Gets the value used for voxels which are outside the volume.

The border value is returned whenever an attempt is made to read a voxel which is outside the extents of the volume.

Returns:: The value used for voxels outside of the volume

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 63 of file RawVolume.inl.

Referenced by PolyVox::RawVolume< VoxelType >::getVoxelAt().

template<typename VoxelType >

VoxelType PolyVox::RawVolume< VoxelType >::getVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)			const

Gets a voxel at the position given by x,y,z coordinates.

Parameters:

	uXPos	The `x` position of the voxel
	uYPos	The `y` position of the voxel
	uZPos	The `z` position of the voxel

Returns:: The voxel value

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 75 of file RawVolume.inl.

Referenced by PolyVox::LowPassFilter< SrcVolumeType, DestVolumeType, VoxelType >::executeSAT(), and PolyVox::RawVolume< VoxelType >::getVoxelAt().

Here is the call graph for this function:

template<typename VoxelType >

VoxelType PolyVox::RawVolume< VoxelType >::getVoxelAt ( const Vector3DInt32 & v3dPos ) const

Gets a voxel at the position given by a 3D vector.

Parameters:

v3dPos

The 3D position of the voxel

Returns:: The voxel value

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 102 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

void PolyVox::RawVolume< VoxelType >::resize ( const Region & regValidRegion )

Deprecated - I don't think we should expose this function? Let us know if you disagree...

This function should probably be made internal...

Definition at line 164 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

void PolyVox::RawVolume< VoxelType >::setBorderValue ( const VoxelType & tBorder )

Sets the value used for voxels which are outside the volume.

Parameters:

tBorder

The value to use for voxels outside the volume.

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 111 of file RawVolume.inl.

template<typename VoxelType >

bool PolyVox::RawVolume< VoxelType >::setVoxelAt	(	const Vector3DInt32 &	v3dPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by a 3D vector.

Parameters:

	v3dPos	the 3D position of the voxel
	tValue	the value to which the voxel will be set

Returns:: whether the requested position is inside the volume

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 155 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

bool PolyVox::RawVolume< VoxelType >::setVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by x,y,z coordinates.

Parameters:

	uXPos	the `x` position of the voxel
	uYPos	the `y` position of the voxel
	uZPos	the `z` position of the voxel
	tValue	the value to which the voxel will be set

Returns:: whether the requested position is inside the volume

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 124 of file RawVolume.inl.

Referenced by PolyVox::LowPassFilter< SrcVolumeType, DestVolumeType, VoxelType >::executeSAT(), and PolyVox::RawVolume< VoxelType >::setVoxelAt().

Here is the call graph for this function:

The documentation for this class was generated from the following files:

PolyVoxCore/include/PolyVoxCore/RawVolume.h
PolyVoxCore/include/PolyVoxCore/RawVolume.inl
