#include <RawVolume.h>

Inheritance diagram for PolyVox::RawVolume< VoxelType >:

Collaboration diagram for PolyVox::RawVolume< VoxelType >:

Classes
class	Sampler

Public Member Functions
	RawVolume (const Region &regValid)
	Constructor for creating a fixed size volume.

	~RawVolume ()
	Destructor.

VoxelType	getVoxel (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by `x,y,z` coordinates.

VoxelType	getVoxel (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.

VoxelType	getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by `x,y,z` coordinates.

VoxelType	getVoxelAt (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.

VoxelType	getVoxelWithWrapping (int32_t uXPos, int32_t uYPos, int32_t uZPos, WrapMode eWrapMode=WrapModes::Border, VoxelType tBorder=VoxelType()) const
	Gets a voxel at the position given by `x,y,z` coordinates.

VoxelType	getVoxelWithWrapping (const Vector3DInt32 &v3dPos, WrapMode eWrapMode=WrapModes::Border, VoxelType tBorder=VoxelType()) const
	Gets a voxel at the position given by a 3D vector.

bool	setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue)
	Sets the voxel at the position given by `x,y,z` coordinates.

bool	setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue)
	Sets the voxel at the position given by a 3D vector.

uint32_t	calculateSizeInBytes (void)
	Calculates approximatly how many bytes of memory the volume is currently using.

Public Member Functions inherited from PolyVox::BaseVolume< VoxelType >
VoxelType	getBorderValue (void) const
	Gets the value used for voxels which are outside the volume.

const Region &	getEnclosingRegion (void) const
	Gets a Region representing the extents of the Volume.

int32_t	getWidth (void) const
	Gets the width of the volume in voxels.

int32_t	getHeight (void) const
	Gets the height of the volume in voxels.

int32_t	getDepth (void) const
	Gets the depth of the volume in voxels.

int32_t	getLongestSideLength (void) const
	Gets the length of the longest side in voxels.

int32_t	getShortestSideLength (void) const
	Gets the length of the shortest side in voxels.

float	getDiagonalLength (void) const
	Gets the length of the diagonal in voxels.

VoxelType	getVoxel (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by `x,y,z` coordinates.

VoxelType	getVoxel (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.

VoxelType	getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by `x,y,z` coordinates.

VoxelType	getVoxelAt (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.

VoxelType	getVoxelWithWrapping (int32_t uXPos, int32_t uYPos, int32_t uZPos, WrapMode eWrapMode=WrapModes::Border, VoxelType tBorder=VoxelType()) const
	Gets a voxel at the position given by `x,y,z` coordinates.

VoxelType	getVoxelWithWrapping (const Vector3DInt32 &v3dPos, WrapMode eWrapMode=WrapModes::Border, VoxelType tBorder=VoxelType()) const
	Gets a voxel at the position given by a 3D vector.

void	setBorderValue (const VoxelType &tBorder)
	Sets the value used for voxels which are outside the volume.

bool	setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue)
	Sets the voxel at the position given by `x,y,z` coordinates.

bool	setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue)
	Sets the voxel at the position given by a 3D vector.

uint32_t	calculateSizeInBytes (void)
	Calculates approximatly how many bytes of memory the volume is currently using.

Protected Member Functions
	RawVolume (const RawVolume &rhs)
	Copy constructor.

RawVolume &	operator= (const RawVolume &rhs)
	Assignment operator.

Protected Member Functions inherited from PolyVox::BaseVolume< VoxelType >
	BaseVolume (const Region &regValid)
	Constructor for creating a fixed size volume.

	BaseVolume (const BaseVolume &rhs)
	Copy constructor.

	~BaseVolume ()
	Destructor.

BaseVolume &	operator= (const BaseVolume &rhs)
	Assignment operator.

Additional Inherited Members
Public Types inherited from PolyVox::BaseVolume< VoxelType >
typedef VoxelType	VoxelType

Protected Attributes inherited from PolyVox::BaseVolume< VoxelType >
Region	m_regValidRegion

int32_t	m_uLongestSideLength

int32_t	m_uShortestSideLength

float	m_fDiagonalLength

VoxelType	m_tBorderValue

Detailed Description

template<typename VoxelType>
class PolyVox::RawVolume< VoxelType >

Definition at line 40 of file RawVolume.h.

Constructor & Destructor Documentation

template<typename VoxelType >

RawVolume< VoxelType >::RawVolume ( const Region & regValid )

Constructor for creating a fixed size volume.

This constructor creates a volume with a fixed size which is specified as a parameter.

Parameters

regValid Specifies the minimum and maximum valid voxel positions.

Definition at line 31 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

RawVolume< VoxelType >::~RawVolume ( )

Destructor.

Destroys the volume.

Definition at line 57 of file RawVolume.inl.

template<typename VoxelType >

RawVolume< VoxelType >::RawVolume ( const RawVolume< VoxelType > & rhs )

protected

Copy constructor.

This function should never be called.

Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.

See Also: VolumeResampler

Definition at line 48 of file RawVolume.inl.

Member Function Documentation

template<typename VoxelType >

uint32_t RawVolume< VoxelType >::calculateSizeInBytes ( void )

Calculates approximatly how many bytes of memory the volume is currently using.

Note: This function needs reviewing for accuracy...

Definition at line 275 of file RawVolume.inl.

template<typename VoxelType >

VoxelType RawVolume< VoxelType >::getVoxel	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters

uXPos	The `x` position of the voxel
uYPos	The `y` position of the voxel
uZPos	The `z` position of the voxel

Returns: The voxel value

Definition at line 83 of file RawVolume.inl.

template<typename VoxelType >

VoxelType RawVolume< VoxelType >::getVoxel ( const Vector3DInt32 & v3dPos ) const

Gets a voxel at the position given by a 3D vector.

Parameters

v3dPos The 3D position of the voxel

Returns: The voxel value

Definition at line 105 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

VoxelType RawVolume< VoxelType >::getVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters

uXPos	The `x` position of the voxel
uYPos	The `y` position of the voxel
uZPos	The `z` position of the voxel

Returns: The voxel value

Definition at line 117 of file RawVolume.inl.

Referenced by PolyVox::LowPassFilter< SrcVolumeType, DstVolumeType, AccumulationType >::executeSAT(), and PolyVox::RawVolume< VoxelType >::Sampler::getVoxel().

Here is the call graph for this function:

template<typename VoxelType >

VoxelType RawVolume< VoxelType >::getVoxelAt ( const Vector3DInt32 & v3dPos ) const

Gets a voxel at the position given by a 3D vector.

Parameters

v3dPos The 3D position of the voxel

Returns: The voxel value

Definition at line 144 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

VoxelType RawVolume< VoxelType >::getVoxelWithWrapping	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos,
		WrapMode	eWrapMode = `WrapModes::Border`,
		VoxelType	tBorder = `VoxelType()`
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters

uXPos	The `x` position of the voxel
uYPos	The `y` position of the voxel
uZPos	The `z` position of the voxel

Returns: The voxel value

Definition at line 156 of file RawVolume.inl.

template<typename VoxelType >

VoxelType RawVolume< VoxelType >::getVoxelWithWrapping	(	const Vector3DInt32 &	v3dPos,
		WrapMode	eWrapMode = `WrapModes::Border`,
		VoxelType	tBorder = `VoxelType()`
	)		const

Gets a voxel at the position given by a 3D vector.

Parameters

v3dPos The 3D position of the voxel

Returns: The voxel value

Definition at line 200 of file RawVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

RawVolume< VoxelType > & RawVolume< VoxelType >::operator= ( const RawVolume< VoxelType > & rhs )

protected

Assignment operator.

This function should never be called.

Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.
