PolyVox::BaseVolume< _VoxelType > Class Template Reference

#include <BaseVolume.h>

Inheritance diagram for PolyVox::BaseVolume< _VoxelType >:

Collaboration diagram for PolyVox::BaseVolume< _VoxelType >:

Classes
class	Sampler

Public Types
typedef _VoxelType	VoxelType

Public Member Functions
VoxelType	getBorderValue (void) const
	Gets the value used for voxels which are outside the volume.
const Region &	getEnclosingRegion (void) const
	Gets a Region representing the extents of the Volume.
int32_t	getWidth (void) const
	Gets the width of the volume in voxels.
int32_t	getHeight (void) const
	Gets the height of the volume in voxels.
int32_t	getDepth (void) const
	Gets the depth of the volume in voxels.
int32_t	getLongestSideLength (void) const
	Gets the length of the longest side in voxels.
int32_t	getShortestSideLength (void) const
	Gets the length of the shortest side in voxels.
float	getDiagonalLength (void) const
	Gets the length of the diagonal in voxels.
VoxelType	getVoxel (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by x,y,z coordinates.
VoxelType	getVoxel (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.
VoxelType	getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by x,y,z coordinates.
VoxelType	getVoxelAt (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.
VoxelType	getVoxelWithWrapping (int32_t uXPos, int32_t uYPos, int32_t uZPos, WrapMode eWrapMode=WrapModes::Border, VoxelType tBorder=VoxelType()) const
	Gets a voxel at the position given by x,y,z coordinates.
VoxelType	getVoxelWithWrapping (const Vector3DInt32 &v3dPos, WrapMode eWrapMode=WrapModes::Border, VoxelType tBorder=VoxelType()) const
	Gets a voxel at the position given by a 3D vector.
void	setBorderValue (const VoxelType &tBorder)
	Sets the value used for voxels which are outside the volume.
bool	setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue)
	Sets the voxel at the position given by x,y,z coordinates.
bool	setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue)
	Sets the voxel at the position given by a 3D vector.
uint32_t	calculateSizeInBytes (void)
	Calculates approximatly how many bytes of memory the volume is currently using.

Protected Member Functions
	BaseVolume (const Region &regValid)
	Constructor for creating a fixed size volume.
	BaseVolume (const BaseVolume &rhs)
	Copy constructor.
	~BaseVolume ()
	Destructor.
BaseVolume &	operator= (const BaseVolume &rhs)
	Assignment operator.

Protected Attributes
Region	m_regValidRegion
int32_t	m_uLongestSideLength
int32_t	m_uShortestSideLength
float	m_fDiagonalLength
VoxelType	m_tBorderValue

Detailed Description

template<typename _VoxelType>
class PolyVox::BaseVolume< _VoxelType >

Definition at line 51 of file BaseVolume.h.

Member Typedef Documentation

template<typename _VoxelType>

typedef _VoxelType PolyVox::BaseVolume< _VoxelType >::VoxelType

Definition at line 54 of file BaseVolume.h.

Constructor & Destructor Documentation

template<typename VoxelType >

PolyVox::BaseVolume< VoxelType >::BaseVolume ( const Region &  regValid )

protected

Constructor for creating a fixed size volume.

This is protected because you should never create a BaseVolume directly, you should instead use one of the derived classes.

See Also

RawVolume, SimpleVolume, LargeVolume

Definition at line 32 of file BaseVolume.inl.

template<typename VoxelType >

PolyVox::BaseVolume< VoxelType >::BaseVolume ( const BaseVolume< _VoxelType > &  rhs )

protected

Copy constructor.

This function should never be called.

Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the VolumeResampler.

See Also

VolumeResampler

Definition at line 46 of file BaseVolume.inl.

template<typename VoxelType >

PolyVox::BaseVolume< VoxelType >::~BaseVolume ( )

protected

Destructor.

Destroys the volume.

Definition at line 55 of file BaseVolume.inl.

Member Function Documentation

template<typename VoxelType >

uint32_t PolyVox::BaseVolume< VoxelType >::calculateSizeInBytes

(

void

)

Calculates approximatly how many bytes of memory the volume is currently using.

Note: This function needs reviewing for accuracy...

Definition at line 267 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getBorderValue

(

void

)

const

Gets the value used for voxels which are outside the volume.

The border value is returned whenever an attempt is made to read a voxel which is outside the extents of the volume.

Returns

The value used for voxels outside of the volume

Definition at line 78 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getDepth

(

void

)

const

Gets the depth of the volume in voxels.

Returns

The depth of the volume in voxels. Note that this value is inclusive, so that if the valid range is e.g. 0 to 63 then the depth is 64.

See Also

getWidth(), getHeight()

Definition at line 117 of file BaseVolume.inl.

template<typename VoxelType >

float PolyVox::BaseVolume< VoxelType >::getDiagonalLength

(

void

)

const

Gets the length of the diagonal in voxels.

Returns

The length of the diagonal in voxels. For example, if a volume has dimensions 256x512x1024 this function will return sqrt(256*256+512*512+1024*1024) = 1173.139. This value is computed on volume creation so retrieving it is fast.

See Also

getShortestSideLength(), getLongestSideLength()

Definition at line 151 of file BaseVolume.inl.

template<typename VoxelType >

const Region & PolyVox::BaseVolume< VoxelType >::getEnclosingRegion

(

void

)

const

Gets a Region representing the extents of the Volume.

Returns

A Region representing the extent of the volume.

Definition at line 87 of file BaseVolume.inl.

Referenced by PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::moveNegativeX(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::moveNegativeY(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::moveNegativeZ(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::movePositiveX(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::movePositiveY(), and PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::movePositiveZ().

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getHeight

(

void

)

const

Gets the height of the volume in voxels.

Returns

The height of the volume in voxels. Note that this value is inclusive, so that if the valid range is e.g. 0 to 63 then the height is 64.

See Also

getWidth(), getDepth()

Definition at line 107 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getLongestSideLength

(

void

)

const

Gets the length of the longest side in voxels.

Returns

The length of the longest side in voxels. For example, if a volume has dimensions 256x512x1024 this function will return 1024.

See Also

getShortestSideLength(), getDiagonalLength()

Definition at line 139 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getShortestSideLength

(

void

)

const

Gets the length of the shortest side in voxels.

Returns

The length of the shortest side in voxels. For example, if a volume has dimensions 256x512x1024 this function will return 256.

See Also

getLongestSideLength(), getDiagonalLength()

Definition at line 128 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxel	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters

uXPos	The x position of the voxel
uYPos	The y position of the voxel
uZPos	The z position of the voxel

Returns

The voxel value

Definition at line 163 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxel

(

const Vector3DInt32 &

v3dPos

)

const

Gets a voxel at the position given by a 3D vector.

Parameters

v3dPos

The 3D position of the voxel

Returns

The voxel value

Definition at line 174 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters

uXPos	The x position of the voxel
uYPos	The y position of the voxel
uZPos	The z position of the voxel

Returns

The voxel value

Definition at line 187 of file BaseVolume.inl.

Referenced by PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px0py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px0py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px0py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1ny0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1ny1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1ny1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx0py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx0py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx0py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1ny0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1ny1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1ny1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px0py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px0py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px0py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1ny0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1ny1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1ny1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1py1nz(), and PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1py1pz().

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelAt

(

const Vector3DInt32 &

v3dPos

)

const

Gets a voxel at the position given by a 3D vector.

Parameters

v3dPos

The 3D position of the voxel

Returns

The voxel value

Definition at line 198 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelWithWrapping	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos,
		WrapMode	eWrapMode = WrapModes::Border,
		VoxelType	tBorder = VoxelType()
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters

uXPos	The x position of the voxel
uYPos	The y position of the voxel
uZPos	The z position of the voxel

Returns

The voxel value

Definition at line 211 of file BaseVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelWithWrapping	(	const Vector3DInt32 &	v3dPos,
		WrapMode	eWrapMode = WrapModes::Border,
		VoxelType	tBorder = VoxelType()
	)		const

Gets a voxel at the position given by a 3D vector.

Parameters

v3dPos

The 3D position of the voxel

Returns

The voxel value

Definition at line 222 of file BaseVolume.inl.

template<typename VoxelType >

int32_t PolyVox::BaseVolume< VoxelType >::getWidth

(

void

)

const

Gets the width of the volume in voxels.

Returns

The width of the volume in voxels. Note that this value is inclusive, so that if the valid range is e.g. 0 to 63 then the width is 64.

See Also

getHeight(), getDepth()

Definition at line 97 of file BaseVolume.inl.

template<typename VoxelType >

BaseVolume< VoxelType > & PolyVox::BaseVolume< VoxelType >::operator= ( const BaseVolume< _VoxelType > &  rhs )

protected

Assignment operator.

This function should never be called.

Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.

See Also

VolumeResampler

Definition at line 67 of file BaseVolume.inl.

template<typename VoxelType >

void PolyVox::BaseVolume< VoxelType >::setBorderValue

(

const VoxelType &

tBorder

)

Sets the value used for voxels which are outside the volume.

Parameters

tBorder

The value to use for voxels outside the volume.

Definition at line 232 of file BaseVolume.inl.

template<typename VoxelType >

bool PolyVox::BaseVolume< VoxelType >::setVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by x,y,z coordinates.

Parameters

uXPos	the x position of the voxel
uYPos	the y position of the voxel
uZPos	the z position of the voxel
tValue	the value to which the voxel will be set

Returns

whether the requested position is inside the volume

Definition at line 245 of file BaseVolume.inl.

Referenced by PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::setVoxel().

template<typename VoxelType >

bool PolyVox::BaseVolume< VoxelType >::setVoxelAt	(	const Vector3DInt32 &	v3dPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by a 3D vector.

Parameters

v3dPos	the 3D position of the voxel
tValue	the value to which the voxel will be set

Returns

whether the requested position is inside the volume

Definition at line 257 of file BaseVolume.inl.

Member Data Documentation

template<typename _VoxelType>

float PolyVox::BaseVolume< _VoxelType >::m_fDiagonalLength

protected

Definition at line 192 of file BaseVolume.h.

template<typename _VoxelType>

Region PolyVox::BaseVolume< _VoxelType >::m_regValidRegion

protected

Definition at line 187 of file BaseVolume.h.

template<typename _VoxelType>

VoxelType PolyVox::BaseVolume< _VoxelType >::m_tBorderValue

protected

Definition at line 195 of file BaseVolume.h.

template<typename _VoxelType>

int32_t PolyVox::BaseVolume< _VoxelType >::m_uLongestSideLength

protected

Definition at line 190 of file BaseVolume.h.

template<typename _VoxelType>

int32_t PolyVox::BaseVolume< _VoxelType >::m_uShortestSideLength

protected

Definition at line 191 of file BaseVolume.h.

---

The documentation for this class was generated from the following files:

• PolyVoxCore/include/PolyVoxCore/BaseVolume.h
• PolyVoxCore/include/PolyVoxCore/BaseVolume.inl
