PolyVox::SimpleVolume< VoxelType > Class Template Reference

#include <SimpleVolume.h>

Inheritance diagram for PolyVox::SimpleVolume< VoxelType >:

Collaboration diagram for PolyVox::SimpleVolume< VoxelType >:

List of all members.

Classes
class	Block
class	Sampler

Public Member Functions
	SimpleVolume (const Region &regValid, uint16_t uBlockSideLength=32)
	Constructor for creating a fixed size volume.
	~SimpleVolume ()
	Destructor.
VoxelType	getBorderValue (void) const
	Gets the value used for voxels which are outside the volume.
VoxelType	getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const
	Gets a voxel at the position given by x,y,z coordinates.
VoxelType	getVoxelAt (const Vector3DInt32 &v3dPos) const
	Gets a voxel at the position given by a 3D vector.
void	setBorderValue (const VoxelType &tBorder)
	Sets the value used for voxels which are outside the volume.
bool	setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue)
	Sets the voxel at the position given by x,y,z coordinates.
bool	setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue)
	Sets the voxel at the position given by a 3D vector.
uint32_t	calculateSizeInBytes (void)
	Calculates approximatly how many bytes of memory the volume is currently using.
Public Member Functions inherited from PolyVox::BaseVolume< VoxelType >
Region	getEnclosingRegion (void) const
	Gets a Region representing the extents of the Volume.
int32_t	getWidth (void) const
	Gets the width of the volume in voxels.
int32_t	getHeight (void) const
	Gets the height of the volume in voxels.
int32_t	getDepth (void) const
	Gets the depth of the volume in voxels.
int32_t	getLongestSideLength (void) const
	Gets the length of the longest side in voxels.
int32_t	getShortestSideLength (void) const
	Gets the length of the shortest side in voxels.
float	getDiagonalLength (void) const
	Gets the length of the diagonal in voxels.

Protected Member Functions
	SimpleVolume (const SimpleVolume &rhs)
	Copy constructor.
SimpleVolume &	operator= (const SimpleVolume &rhs)
	Assignment operator.
Protected Member Functions inherited from PolyVox::BaseVolume< VoxelType >
	BaseVolume (const Region &regValid)
	Constructor for creating a fixed size volume.
	BaseVolume (const BaseVolume &rhs)
	Copy constructor.
	~BaseVolume ()
	Destructor.
BaseVolume &	operator= (const BaseVolume &rhs)
	Assignment operator.

Additional Inherited Members
Public Types inherited from PolyVox::BaseVolume< VoxelType >
typedef VoxelType	VoxelType
Protected Attributes inherited from PolyVox::BaseVolume< VoxelType >
Region	m_regValidRegion
int32_t	m_uLongestSideLength
int32_t	m_uShortestSideLength
float	m_fDiagonalLength

---

Detailed Description

template<typename VoxelType>
class PolyVox::SimpleVolume< VoxelType >

Definition at line 44 of file SimpleVolume.h.

---

Constructor & Destructor Documentation

template<typename VoxelType >

PolyVox::SimpleVolume< VoxelType >::SimpleVolume	(	const Region &	regValid,
		uint16_t	uBlockSideLength = 32
	)

Constructor for creating a fixed size volume.

This constructor creates a volume with a fixed size which is specified as a parameter.

Parameters:

regValid	Specifies the minimum and maximum valid voxel positions.
uBlockSideLength	The size of the block to use within the volume

Definition at line 32 of file SimpleVolume.inl.

template<typename VoxelType >

PolyVox::SimpleVolume< VoxelType >::~SimpleVolume

(

)

Destructor.

Destroys the volume.

Definition at line 56 of file SimpleVolume.inl.

template<typename VoxelType >

PolyVox::SimpleVolume< VoxelType >::SimpleVolume ( const SimpleVolume< VoxelType > &  rhs )

protected

Copy constructor.

This function should never be called.

Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.

See also:

VolumeResampler

Definition at line 47 of file SimpleVolume.inl.

---

Member Function Documentation

template<typename VoxelType >

uint32_t PolyVox::SimpleVolume< VoxelType >::calculateSizeInBytes

(

void

)

Calculates approximatly how many bytes of memory the volume is currently using.

Todo:

This function needs reviewing for accuracy...

Returns:

The number of bytes used

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 271 of file SimpleVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::SimpleVolume< VoxelType >::getBorderValue

(

void

)

const

Gets the value used for voxels which are outside the volume.

The border value is returned whenever an attempt is made to read a voxel which is outside the extents of the volume.

Returns:

The value used for voxels outside of the volume

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 81 of file SimpleVolume.inl.

template<typename VoxelType >

VoxelType PolyVox::SimpleVolume< VoxelType >::getVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos
	)		const

Gets a voxel at the position given by x,y,z coordinates.

Parameters:

uXPos	The x position of the voxel
uYPos	The y position of the voxel
uZPos	The z position of the voxel

Returns:

The voxel value

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 93 of file SimpleVolume.inl.

Referenced by PolyVox::SimpleVolume< VoxelType >::Block::getVoxelAt(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px0py1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px0py1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px1ny0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px1ny1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px1ny1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px1py0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px1py1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel0px1py1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx0py0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx0py1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx0py1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx1ny0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx1ny1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx1ny1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx1py0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx1py1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1nx1py1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px0py0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px0py1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px0py1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px1ny0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px1ny1nz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px1ny1pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px1py0pz(), PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px1py1nz(), and PolyVox::SimpleVolume< VoxelType >::Sampler::peekVoxel1px1py1pz().

Here is the call graph for this function:

template<typename VoxelType >

VoxelType PolyVox::SimpleVolume< VoxelType >::getVoxelAt

(

const Vector3DInt32 &

v3dPos

)

const

Gets a voxel at the position given by a 3D vector.

Parameters:

v3dPos

The 3D position of the voxel

Returns:

The voxel value

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 120 of file SimpleVolume.inl.

Here is the call graph for this function:

template<typename VoxelType >

SimpleVolume< VoxelType > & PolyVox::SimpleVolume< VoxelType >::operator= ( const SimpleVolume< VoxelType > &  rhs )

protected

Assignment operator.

This function should never be called.

Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.

See also:

VolumeResampler

Definition at line 70 of file SimpleVolume.inl.

template<typename VoxelType >

void PolyVox::SimpleVolume< VoxelType >::setBorderValue

(

const VoxelType &

tBorder

)

Sets the value used for voxels which are outside the volume.

Parameters:

tBorder

The value to use for voxels outside the volume.

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 129 of file SimpleVolume.inl.

template<typename VoxelType >

bool PolyVox::SimpleVolume< VoxelType >::setVoxelAt	(	int32_t	uXPos,
		int32_t	uYPos,
		int32_t	uZPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by x,y,z coordinates.

Parameters:

uXPos	the x position of the voxel
uYPos	the y position of the voxel
uZPos	the z position of the voxel
tValue	the value to which the voxel will be set

Returns:

whether the requested position is inside the volume

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 144 of file SimpleVolume.inl.

Referenced by PolyVox::SimpleVolume< VoxelType >::Block::setVoxelAt().

template<typename VoxelType >

bool PolyVox::SimpleVolume< VoxelType >::setVoxelAt	(	const Vector3DInt32 &	v3dPos,
		VoxelType	tValue
	)

Sets the voxel at the position given by a 3D vector.

Parameters:

v3dPos	the 3D position of the voxel
tValue	the value to which the voxel will be set

Returns:

whether the requested position is inside the volume

Reimplemented from PolyVox::BaseVolume< VoxelType >.

Definition at line 170 of file SimpleVolume.inl.

Referenced by PolyVox::SimpleVolume< VoxelType >::setVoxelAt().

Here is the call graph for this function:

---

The documentation for this class was generated from the following files:

• PolyVoxCore/include/PolyVoxCore/SimpleVolume.h
• PolyVoxCore/include/PolyVoxCore/SimpleVolume.inl
